| Solera 189 | |
| Length on Trailer (Towing Length) | 25' 6" |
| Length on Trailer (with Motor in Towing Position and Swing-Away Tongue Folded) | 22' 10" |
| Length on Trailer w/Motor Trimmed Vertical w/Swing-Away Tongue Folded (shortest length) | 21' 5" |
| Width on Trailer | 102" |
| Boat Length | 18' 9" |
| Beam | 100" |
| Engine Shaft Length | 25" |
| Max. Height on Trailer (Walk-Through W/S) | 81" |
| Interior Depth (at console) | 25" |
| Draft | 16" |
| Standard Boat Weight | 2300 lbs. |
| Max. H.P. | 200 h.p |
| Max.Weight | 1520 |
| Maximum Persons | 6 Persons/ 846 lbs |
| Fuel Capacity | 34 Gals. |
| Solera 189 | Solera 205 | |
|---|---|---|
| Humminbird Electronics | ||
| Helix 7 CHIRP GPS G4N w/ temp (Dash) (Flush) | S | S |
| Helix 7 CHIRP GPS G4N w/ temp (Bow) (Flush) | O | NA |
| Helix 7 CHIRP GPS G4N w/ temp (Bow) (Flush) | NA | O |
| Helix 9 CHIRP GPS G4N w/ temp (Bow) (Flush) | NA | O |
| No Std. Electronics | O | O |
| Humminbird Network Cable (Installed Dash to Bow) (Inc. w/ bow unit) | O | O |
| Solix 2D Rear to Dash (Each Installed) | O | O |
| Helix 2D Rear to Dash (Each Installed) | O | O |
| Solera 189 | Solera 205 | |
|---|---|---|
| Fuel System | S (34 Gal) | S (41 Gal) |
| 8" Engine Setback Plate | S | S |
| Torque Transfer System | S | S |
| Livewell Control System featuring Independent Fill, Recirculating & Drain Modes w/ Pump Timer | S | S |
| Stern Livewell | S (24 Gal) | S (24 Gal) |
| Bow Baitwell | S (8 Gal) | S (8 Gal) |
| Oxygenator Livewell Aeration System (Front Baitwell & Rear Livewell) | O | O |
| Auto or Manual 1100 GPH Bilge Pump | S | S |
| Radio w/ Speakers (4) | S | S |
| Ski Tow Pylon | S | S |
| Console Storm Guard | O | O |
| Bimini Top | S | S |
| Minn Kota 10 Amp x 3-Bank Battery Charger | S | NA |
| Minn Kota 10 Amp x 4-Bank Battery Charger | NA | S |
| Kicker Engine | NA | O |
| T9.9XPB 25" Kicker Engine (Requires Factory Rigging and Remote Control) | NA | O |
| Remote Control for T9.9R Kicker Engine (Installed) | NA | O |
| Kicker Factory Rigging (Includes setback) (Port) | NA | O |
| Black Kicker Cowl | NA | O |
| Tilt Hydraulic Steering | S | S |
| Prop Deduct | O | O |
| SS Prop Recommended for Water Sports (exchange) | O | NA |
| Dry Dock ventilation system | S | S |
| Remote Drain Plug | S | S |
| EVA Cockpit Flooring | S | S |
| Minn Kota Troll Motors | ||
| 24v | ||
| MK Terrova 80/US2/IP-60"_BT w/sliding removable mount | S | NA |
| MK Terrova 80/MDI/IP-LINK-60"_BT w/sliding removable mount (exchange) | O | NA |
| MK Ulterra 80/US2/IP-60"_BT w/sliding removable mount (exchange) | O | NA |
| MK Ulterra 80/MDI/IP-LINK-60"_BT w/sliding removable mount (exchange) | O | NA |
| 36v | ||
| MK Terrova 112/US2/IP-60"_BT w/sliding removable mount | NA | S |
| MK Terrova 112/MDI/IP-LINK-60"_BT w/sliding removable mount (exchange) | NA | O |
| MK Ulterra 112/US2/IP-60"_BT w/sliding removable mount (exchange) | NA | O |
| MK Ulterra 112/MDI/IP-LINK-60"_BT w/sliding removable mount (exchange) | NA | O |
| MK Ulterra 112/US2/IP-72"_BT w/sliding removable mount (exchange) | NA | O |
| MK Ulterra 112/MDI/IP-LINK-72"_BT w/sliding removable mount (exchange) | NA | O |
| No Troll Motor or Sliding Removable Mount | O | NA |
| Solera 189 | Solera 205 | |
|---|---|---|
| Construction & Safety | ||
| Stainless Cleats | S (4) | S (4) |
| Compression Latch/Locking System | S | S |
| Floor Rod/ Ski Storage Box (7‘ rods) | S | S |
| Side-Wall Rod Storage (10‘ rods) | S | S |
| Interior Lighting | S | S |
| Integrated Boarding Ladder (Starboard mounting) | S | S |
| Hamby Keel Protector | O | O |
| Custom Boat Cover (Black) | O | O |
| Solera 189 | Solera 205 | |
|---|---|---|
| Skeeter Built Trailer w/Tuff Coat, Channel Frame, Steel Fenders w EVA, Single Torsion Axle w/ Disc Brakes & 15" Silver Aluminum Wheels | S | NA |
| Skeeter Built Trailer w/Tuff Coat, Channel Frame, Steel Fenders w EVA, Tandem Torsion Axles w/ Dual Disc Brakes & 14" Aluminum Wheels | O | S |
| Swing-Away Tongue | S | S |
| Fulton F2 Jack-Stand & Winch | S | S |
| Skeeter Cutouts | S | S |
| Ratchet Tie-Downs | S | S |
| Spare Tire & Carrier | S | S |
| Winch Post Ladder | S | S |
| Backup Lights | O | O |
